Technical Parameters
| Item | Unit | Parameter |
| Max. pressing force | KN | 10000 |
| Ejecting force | KN | 210 |
| Max. beam stroke | mm | 140 |
| Min. distance between beam and press table | mm | 380 |
| Max. distance between beam and press table | mm | 520 |
| Distance between left and right columns | mm | 1440 |
| Reserved width of column | mm | 530 |
| Max. filler thickness | mm | 60 |
| Idle cycle index | Min-1 | 25 |
| Pressing frequency per cycle | times | 2~3 |
| Main motor capacity | KW | 55 |
| Oil volume | L | 700 |
| Air consumption | m³/h | 0.25 |
| Cooling water volume | m³/h | 18 |
| Weight of main components | t | 40 |
ZZ1000 is applicable for all specifications of external tiles, strip tiles and mosaic tiles.
